The new EF2200iST offers 2,200 watts of superior, confident power output and world-class Yamaha reliability for the RV, the job site, home backup, tailgating, or anywhere else you need clean, portable power.
- There are no features available
Engine |
|
Model |
MZ80, 79 cc, air-cooled (fan assist), OHV, 2-valve, 4-stroke |
Starting System |
Manual Recoil |
Ignition |
Transistor Controlled Ignition (TCI) |
Recommended Fuel |
87 octane regular gasoline |
Engine Oil Capacity |
0.32 L |
General |
|
L x W x H mm (in) |
555 x 300 x 475 mm (21.9 x 11.8 x 18.7") |
Dry Weight |
25 kg / (55 lb) |
Fuel Tank Capacity (L) |
4.7 L |
Operating Hours (@ 1 / 4 load) |
10.5 hrs |
Operating Hours (@ rated load) |
4.2 hrs |
Noise Level (@ 7 metres) |
65 dB |
Generator |
|
Type |
Brushless Inverter |
Maximum AC Output (watts / amperes) |
2,200 W / 18.3 A |
Rated AC Output (watts / amperes) - Continuous Use |
1,800 W / 15 A |
Rated AC Output (watts / amperes) - Continuous Use – "Twinned" Units |
3,600 W / 25 A |
AC Voltage & Frequency (HZ) |
120 V / 60 HZ |
Voltage Regulator |
Inverter (Pulse Width Modulation) |
Neutral |
Floating |
DC Output (volts / amp) |
12 V / 3 A |
Technical Features |
|
Non-Fuse Circuit Breaker System (NFB) |
Standard |
Pilot Lamp (AC output) |
Standard |
Warning Lamps (overload / low oil) |
Standard |
Smart Throttle / Economy Control |
Standard |
Oil Watch Warning System |
Standard |
Oil Pressure Warning System (Engine Shut Down) |
Standard |
Power Meter |
Standard |
Hour Meter |
Standard |
Fuel Level Gauge |
Standard |
Noise Block (enclosed engine design) |
Standard |
Yamaha's Boost Technology (10 second) |
Standard (60 seconds) |
Spark Arrestor |
Standard |
Warranty |
|
Private Use† |
3-years limited |
Commercial Use† |
3-years limited |
