• New High Performance 450cc Four-Stroke Engine
  • The completely redesigned 450cc liquid-cooled DOHC four-stroke engine is lighter, more compact and features stronger pulling power across the entire rev range.
• All-New Aluminum Bilateral Beam Frame

  • A completely redesigned aluminum bilateral beam frame is 15 mm lower at the headtube and has WR450F-specific engine mounts to produce the right blend of strength and flex for the perfect combination of straight-line stability and cornering performance. The result is a better handling machine with lighter feel, more agility and increased traction, allowing the rider to tackle tight, technical trails with greater confidence.
• Class-Leading Suspension

  • The industry-leading, fully adjustable KYB® coil spring-type fork with speed-sensitive damping provides exceptional balance between handling and bump absorption, and now features a new hand operated compression clicker for toolless adjustments. The linkage type rear suspension uses a KYB® shock with specially-tuned damping characteristics to match the WR450F chassis. New settings also result in a 10mm lower seat height than the YZ450F and lower centre of gravity for excellent cornering performance and rider comfort in technical sections.
• Compact Digital Multifunction Display with Fuel Consumption Meter
• Compact headlight and taillight
• High-Capacity Radiator with cooling fan
• Enduro-focused components and specifications

450cc Four-Stroke Engine

The WR450F's advanced four-stroke engine has been designed to be lighter, more compact, higher revving and more powerful across the entire rev range. A

Updated Traction Control System

An all-new Traction Control System communicates wheel slip to the ECU, tuning the engine to help control rear wheel traction. Three levels can be selected: HIGH, LOW or OFF.

Advanced Fuel Injection

The engine breathes through a 44mm Mikuni® throttle body fed by a high-pressure electric pump to ensure optimum fuel atomisation and power for a wide range of altitudes, weather and riding conditions.

Compact Lightweight Clutch

Clutch design uses a disc spring and integrates primary gear and basket into a single steel unit. The result is a more compact, lightweight and durable assembly which yields smooth engagement and excellent feel. Premium clutch cover employs a stylish geometric design that helps minimise scratching and lends a bold look.

Electric Starter System
The WR450F features a compact electric starter system to simplify restarts on the trail and add convenience everywhere else.

Advanced Fuel Injection
The engine breathes through a 44 mm Mikuni throttle body fed by a high-pressure electric pump to ensure optimum fuel atomization and power for a wide range of riding elevations and conditions.

Wide-Ratio Five-Speed Transmission

The WR450F’s wide-ratio 5-speed transmission provides a gear for any off-road location, from tight technical sections to open fields and fire roads. The tri-shaft transmission layout vertically stacks the transmission shafts, raising the centre shaft and forming a triangle between the crank, drive shaft and main shaft for a lighter, more compact transmission.

All-New Aluminium Bilateral Beam Frame

Striking the perfect combination of precise cornering performance and handling stability, the redesigned aluminium bilateral beam frame consists of more than 10 different aluminum components welded together with WR450F-specific engine mounts. The lower frame results in a better handling machine with lighter feel, improved bump absorption and increased traction, allowing the rider to enter corners with greater confidence and more line choices.

Class-Leading Suspension

The industry-leading, fully adjustable KYB® coil spring-type fork with speed-sensitive damping provides exceptional balance between handling and bump absorption, and now features a new hand operated compression clicker for toolless adjustments. The linkage type rear suspension uses a KYB® shock with specially-tuned damping characteristics to match the WR450F chassis. New settings also result in a 10mm lower seat height than YZ450F and lower centre of gravity for improved cornering performance and rider comfort in technical sections.

Slimmer Body & Improved Ergos

A new slimmer, flatter and more compact body eases rider movement for improved control, including more seamless, rounded seat edges, revised side covers and narrower front shrouds. The rider triangle is also improved with increased legroom between the seat and footpegs for enhanced rider comfort.

High Performance Braking System

A large 270mm front brake disc and 240mm rear are coupled with high performance Nissin caliper and aggressive pad material to provide exceptional stopping power and control.

High Performance Details

WR450F boasts a wide range of additional top-spec details carried over from the competition-tested YZ450F including rubber-mounted, four-position adjustable handlebar clamps, aluminium tapered handlebars, wide footpegs and a new quick-adjust clutch perch.

Rider Convenience

WR450F features enduro-developed components including 7.4 litre fuel capacity with fuel, multi-function meter with fuel and engine warning lights, 18-inch rear wheel, composite engine guard, sealed O-ring chain and a folding aluminium kickstand.

Embedded Graphics
Yamaha’s unique embedded graphics are built into the bodywork for extended durability, resisting both peeling and damage.
